Replacement drive motor, pulley, belt, and roller kit used for some Kenmore, Maytag, and Whirlpool dryer models.
Directly Replaces: 279787, 279787SKID, 3387185, 3388237, 3388238, 3391890, 3391891, 3391893, 3395654, 661655, 8528320, 8538263, 8539556, W10250900, W10317045, W10396028, W10438969, W10508322, SM279787, 158, AH334287, AP3094233, EA334287, EAP334287, PD00002347, PS334287, 4392067, 4392067VP, AP3109602, 587637, 80047, 2015, PD00002451, AH373088, EA373088, EAP373088, PS373088, 661570V, AP5983729, 661570, 3387610, 3389728, 3393999, 339728, 661570VP, PS11722115, WP40111201, 40111201, AP4049271, 14218936, 40051501, 40051502, 59174, 821089, AH2041323, EA2041323, PS2041323, R0606549, LB254, WE12X10005, AP3191267, 943875, AH265687, EA265687, PS265687, WPW10314173, W10314173, AP5177441, 8536974, W10314171, 1925071, 3388342, 3389902, 3396801, 3396802, 3401846, 8536973, AH3494614, EA3494614, PS3494614, SAPW10314173, 279640, 697692, 3388672, AP3094197, AH334244, EA334244, PS334244.
Features:
- Includes (1) Drive Motor Assembly, (2) Jumper Wires, (1) Wire Nut, Motor Installation Instructions, (1) Belt, (4) Drum Rollers, (1) Pulley Wheel, (5) Washers, (9) Tri-Rings, Repair Kit Instructions.
APN279787 Motor Specifications:
View APN279787 Instructions
- Color: Gray / Orange / Black / Copper.
- Material: Metal / Plastic.
- Electrical Specs: 120V, 60Hz, 6.2A, 1/3HP, 1725RPM, CL.B.
- Overall Dimensions: 9-3/4"L x 6"W x 5-3/8"H.
- Additional Dimensions: Blower Shaft measures 1-5/8" diameter; Drive Shaft measures 1-1/4" diameter.
*For motor replacements with belt switch - The original motor will have two terminals on the overload protector switch on the motor, the replacement motor only has one. Use the included wire kit and adapt wiring to accept the one terminal on the overload. See included instructions for more detailed information.
APN4392067 Repair Kit Specifications:
View APN4392067 installation instructions
APN40111201 Belt:
- Color: Black.
- Material: Rubber.
- Overall Dimensions: 93-1/2"L x 1/4"W x 1/8"H.
APNW10314173 Roller:
- Color: Black / Dark Green or Black / Red.
- Material: Rubber / Plastic / Metal
- Dimensions: 3-1/8"L x 1"W x 3-1/8"H.
APN279640 Pulley:
- Color: White.
- Material: Plastic / Metal.
- Finish: Matte
- Dimensions: 2 1/8"L x 5/8"W x 2 1/8"H.
Per the manufacturer, if your model also uses the W10837240 idler arm and pulley assembly you may need APN4392067_7240_KIT instead of APN4392067.
Type your model number into the box to filter down the compatible models. How do I find my model number?
Don't see your model listed? Complete this form for help with finding the right part.
3 Reviews
-
Motor kit for dryer
I had to modify one of the connections for my super old dryer. It arrived the day after I ordered it and everything pictured was included. Outstanding value and let me keep my old dryer running instead of buying a new one that so many people seem to be having trouble with. I'll stick with Old Faithful . Great Value , Delivered super fast and exactly what was purchased.
-
Good Replacement Kit
Good kit to replace rollers, belt and motor while you have it all tore down. The only tricky part was having to add the extra jumper wire in from the old to the new motor. The directions for that took a minute, but once I got that, it all worked like a champ. Could possibly add the blower wheel as an option to make it even better.
-
Dryer motor was perfect fit
Fit perfect! Hope to get another 20 years service... Delivery was fast. Great transaction!
